Badeco M3ASF control unit
Product number:
365247
Packaging Unit:
1
From Stock
| Application: | Badeco E2000 – E3001 |
|---|---|
| Article name: | Control unit |
| Brand: | Badeco |
| Dimensions height mm: | 70,00 |
| Dimensions width mm: | 180,00 |
| External dimension length: | 180,00 |
| Manufacturer name: | M3ASF |
| Special feature: | for 2 handpieces |
| Speed R/min: | 2000-20000 |
| Volt/Hz: | 230 V 50 Hz |
| Watt: | 200 |
Manufacturer Informations
Name: Bullnheimer & Co. GmbH & Co. KG
Street: Im Tal 12
City: 86179 Augsburg
Country: DE
Email: info@bullnheimer.de
Phone: + 49 (821) 80 85 0-0
0 of 0 reviews
Login
No reviews found. Be the first to share your insights.
Accessoires (optional)
Robust and handy riveting mallets with precise and uniform impact even during intensive use! The impact force can be adjusted by means of a sleeve on the handpiece itself. The riveting mallets are equipped with an automatic ejection system in case the inserts break (only for Badeco inserts). The new hermetic seal of the mechanical system means that no more maintenance is required. The stroke rate is between 500 and 5000 strokes/min. In addition, clockwise or counter-clockwise rotation of the motor can be used to vary the impact.
Robust and handy riveting mallets with precise and uniform impact even during intensive use! The impact force can be adjusted by means of a sleeve on the handpiece itself. The riveting mallets are equipped with an automatic ejection system in case the inserts break (only for Badeco inserts). The new hermetic seal of the mechanical system means that no more maintenance is required. The stroke rate is between 500 and 5000 strokes/min. In addition, clockwise or counter-clockwise rotation of the motor can be used to vary the impact.
The new filing unit by Badeco has a diameter of only 10 mm and has an anti-vibration effect thanks to its mechanical system. The handpiece will not become hot even after prolonged loads. The ergonomics of the handpiece and the shape of the adjustable file itself allows filing or polishing even at the smallest places and in corners and recesses. It is even possible, to rotate the file 360° during the filing process and thus adapt it to the respective workpiece. The specially designed filing handpiece requires no maintenance or lubrication. Ideal for micro-polishing, filing and deburring not just in hard to reach places! For your safety, we recommend wearing protective goggles and a mask. Stroke length: 1 mm Stroke count: 5000 strokes/min. Vibration: 0.55 m/s2
Product information "Badeco M3ASF control unit"
The ultimate powerhouse with the option of operating two handpieces.
- Infinitely variable speed from 2,000 to 20,000 rpm.
- Equipped with an overload protection. In the event of an overload / overheating, the protection function is triggered to protect the electronics from damage.
- It can be used again after cooling down
- Suitable for max. 2 micromotors
- 2 connections for two-way operation
- Left and right rotation, switch for the direction of rotation on the front of the device
- Manual adjustment of the speed on the device, also as a foot control
- 1 fixed bracket (additional brackets to order).
- 230 V/45 V - 18.3 cNm - 50 V.A. - 200 W (with 2 fuses 250 V - 0.5 AT on the back of the device)
- Color gray
- Dimensions (W x D x H): 180 x 180 x 70 mm
- Compatible with E2000-E3001 micromotor
- Weight approx. 1.4kg
- Infinitely variable speed from 2,000 to 20,000 rpm.
- Equipped with an overload protection. In the event of an overload / overheating, the protection function is triggered to protect the electronics from damage.
- It can be used again after cooling down
- Suitable for max. 2 micromotors
- 2 connections for two-way operation
- Left and right rotation, switch for the direction of rotation on the front of the device
- Manual adjustment of the speed on the device, also as a foot control
- 1 fixed bracket (additional brackets to order).
- 230 V/45 V - 18.3 cNm - 50 V.A. - 200 W (with 2 fuses 250 V - 0.5 AT on the back of the device)
- Color gray
- Dimensions (W x D x H): 180 x 180 x 70 mm
- Compatible with E2000-E3001 micromotor
- Weight approx. 1.4kg
