Tools/supplies

Case opener with handwheel Bergeon

Product number: 235142

Packaging Unit: 1

Delivery time on request

Application:	Screwed cover
Article name:	Case opener
Brand:	Bergeon
Catalogue item No.:	5700-Z
Content:	12,00
Dimensions height mm:	295,00
Dimensions width mm:	95,00
External dimension length:	255,00
Gross weight grams:	3.322
Special feature:	max. 60 mm
Unit content:	Inserts
Unité d'emballage petite:	1

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

Login

Your email address or customer number

Your password

Display reviews in current language only.

No reviews found. Be the first to share your insights.

Accessoires (optional)

Suction cup (top), dia. 16 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 16

Artikel-Nr.: 208913

Suction cup (top), dia. 16 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 19 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 19

Artikel-Nr.: 208914

Suction cup (top), dia. 19 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 22 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 22

Artikel-Nr.: 208915

Suction cup (top), dia. 22 mm for case opener with hand wheel Bergeon

Case holder assortment with 4 pairs Bergeon

Application: für Anstoß 9-22 mm

Artikel-Nr.: 242129

Reversible case holder made of plastic to protect cases. Includes: 2 case holders for stops from 9-11 mm (Bergeon No. 5700-R) 2 case holders for stops from 13-15 mm (Bergeon No. 5700-S) 2 case holders for stops from 17-19 mm (Bergeon No. 5700-T) 2 case holders for stops from 20-22 mm (Bergeon No. 5700-U) In cardboard pack.

Suction cup (top), dia. 40 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 40

Artikel-Nr.: 243993

Suction cup (top), dia. 40 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 45 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 45

Artikel-Nr.: 243994

Suction cup (top), dia. 45 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 50 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 50

Artikel-Nr.: 243995

Suction cup (top), dia. 50 mm for case opener with hand wheel Bergeon

Bergeon support stamp dia. 34 mm

Dimensions Ø mm: 34

Artikel-Nr.: 245370

Round lower stamp made of Adipren dia. 34 mm. With 2 holding pins.

Delrin pressure piece assortment, square

Artikel-Nr.: 301934

For pressing in glasses/closing cases. With thread dia. 6 mm. Includes: 1 pressure piece each: 20x13 mm 25x16 mm 30x19 mm 35x22 mm 40x25 mm 45x28 mm 1 plastic case

Suction cup (top), dia. 34 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 34

Artikel-Nr.: 303654

Suction cup (top), dia. 34 mm for case opener with hand wheel Bergeon

Geriffelter Einsatz RX Ø 36,5 mm

Interior dimension Ø mm: 36.50

Artikel-Nr.: 310318

Passend für Horotec Gehäuseöffner: MSA07.320 = Flume Artikel-Nr. 4220117 MSA07.361 = Flume Artikel-Nr. 4220120 MSA07.363 = Flume Artikel-Nr. 250025 MSA07.368 = Flume Artikel-Nr. 309281 MSA07.305 = Flume Artikel-Nr. 4220034 Passend für Gehäuseöffner Bergeon: 5700...(Flume-Nr. 235142+4220005)

Support stamp, dia. 26 mm made of Adipren, yellow Bergeon

Dimensions Ø mm: 26

Artikel-Nr.: 312178

Round lower stamp made of Adipren dia. 26 mm. With 2 holding pins.

Gehäuseöffnerinsätze BRE Satz 6 Stück Horotec

Application: BRE

Artikel-Nr.: 317528

Satz mit 6 BRE Einsätzen: 1 Einsatz für BRE 12-eckig Innen-Ø 35,5 mm (Flume-Nr.317532) 1 Einsatz für BRE 15-eckig Innen-Ø 34 mm (Flume-Nr.317529) 1 Einsatz für BRE 15-eckig Innen-Ø 35 mm (Flume-Nr.317530) 1 Einsatz für BRE 15-eckig Innen-Ø 36 mm (Flume-Nr.317531) 1 Einsatz für BRE 15-eckig Innen-Ø 37 mm (Flume-Nr.317533) 1 Einsatz für BRE 15-eckig Innen-Ø 38 mm (Flume-Nr.317534) Passend für Horotec Gehäuseöffner: MSA07.320 = Flume Artikel-Nr. 4220117 MSA07.361 = Flume Artikel-Nr. 4220120 MSA07.363 = Flume Artikel-Nr. 250025 MSA07.368 = Flume Artikel-Nr. 309281 Passend für Gehäuseöffner Bergeon 5700...(Flume-Nr. 235142+4220005)

Einsatz für BRE 15-eckig Innen-Ø 34 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 34.00

Artikel-Nr.: 317529

Einsatz für BRE 15-eckig Innen-Ø 35 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 35.00

Artikel-Nr.: 317530

Einsatz für BRE 15-eckig Innen-Ø 36 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 36.00

Artikel-Nr.: 317531

Einsatz für BRE 12-eckig Innen-Ø 35,5 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 35.50

Artikel-Nr.: 317532

Einsatz für BRE 15-eckig Innen-Ø 37 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 37.00

Artikel-Nr.: 317533

Einsatz für BRE 15-eckig Innen-Ø 38 mm für Gehäuseöffner mit Handrad

Interior dimension Ø mm: 38.00

Artikel-Nr.: 317534

Einsatz für OME Seam Ø 33 mm für Gehäuseöffner mit Handrad Horotec

Dimensions Ø mm: 33.00

Artikel-Nr.: 317535

Einsatz für OME Seam Ø 42 mm für Gehäuseöffner mit Handrad

Dimensions Ø mm: 42.00

Artikel-Nr.: 317536

Gehäuseöffnereinsätze OME Seam 4 Stück Horotec

Application: OME

Artikel-Nr.: 317537

Satz mit 4 OME Seam-Einsätzen Ø 20 - 30 - 33 - 42 mm. Passend für Horotec Gehäuseöffner: MSA07.320 = Flume Artikel-Nr. 4220117 MSA07.361 = Flume Artikel-Nr. 4220120 MSA07.363 = Flume Artikel-Nr. 250025 MSA07.368 = Flume Artikel-Nr. 309281 Passend für Gehäuseöffner Bergeon: 5700...(Flume-Nr. 235142+4220005)

Bereon exhauster stamps 9 piece range

Artikel-Nr.: 344346

Compatible with 5700. Suction stamp soft top black Set 9 pieces Ø 16-50 mm

Universal holder for case opener with handwheel Bergeon

Artikel-Nr.: 4220007

With 4 exchangeable holding jaws

Suction cup set (top) for case opener with hand wheel Bergeon

Artikel-Nr.: 4220008

Set of 6 round top suction cups made from Adipren (soft, durable, highly adhesive plastic). The suction cups will not damage sensitive cases. dia. 16 - 19 - 22 - 26 - 30 - 34 mm

Suction cup set (bottom) for case opener with hand wheel Bergeon

Artikel-Nr.: 4220009

Set of 3 height-adjustable stamp pad, made of Adipren plastic, for protecting the case. Dia. 19 - 26 - 34 mm.

6 serrated inserts and adapters for case opener with handwheel Bergeon

Artikel-Nr.: 4220010

Set with 6 corrugated inserts dia. 18.5 - 20.2 - 22.5 - 26.5 - 28.3 - 29.5 mm as well as an adaptor piece for securing the inserts, for opening and closing Rolex cases.

Jaws for cuts for case opener with hand wheel

Artikel-Nr.: 4220012

Fits case openers 4220120 + 4220005 + 235142

Jaws for drilled holes for case opener with hand wheel

Application: 4220120 + 4220005 + 235142

Artikel-Nr.: 4220013

Fits case openers 4220120 + 4220005 + 235142

Holding brackets for universal holder 4220007 Bergeon

Artikel-Nr.: 4220017

Holding brackets for universal holder 4220007 Bergeon

Adaptor for corrugated inserts Bergeon

Artikel-Nr.: 4220018

Fits 4220025 - 4220030

Serrated insert, dia. 18.5 Bergeon

Interior dimension Ø mm: 18.50

Artikel-Nr.: 4220025

Fits case openers 4220106, 4220010, 4220005, 235142.

Serrated insert, dia. 20.2 Bergeon

Interior dimension Ø mm: 20.20

Artikel-Nr.: 4220026

Fits case openers 4220106, 4220010, 4220005, 235142.

Serrated insert, dia. 22.5 Bergeon

Interior dimension Ø mm: 22.50

Artikel-Nr.: 4220027

Fits case openers 4220106, 4220010, 4220005, 235142.

Serrated insert, dia. 26.5 Bergeon

Interior dimension Ø mm: 26.50

Artikel-Nr.: 4220028

Fits case openers 4220106, 4220010, 4220005, 235142.

Serrated insert, dia. 28.3 Bergeon

Interior dimension Ø mm: 28.30

Artikel-Nr.: 4220029

Fits case openers 4220106, 4220010, 4220005, 235142.

Serrated insert, dia. 29.5 Bergeon

Interior dimension Ø mm: 29.50

Artikel-Nr.: 4220030

Fits case openers 4220106, 4220010, 4220005, 235142.

Insert for Omega Speedmaster DAU for case opener with hand wheel Horotec

Dimensions Ø mm: 20.00

Artikel-Nr.: 4220032

Fits 4220117, 4220120, 4220005, 4220034, 235142

Insert for Omega Speedmaster HAU for case opener with hand wheel Horotec

Dimensions Ø mm: 30.00

Artikel-Nr.: 4220033

Fits 4220117, 4220120, 4220005, 4220034, 235142

Inserts B M for Case opener with hand wheel Horotec

Application: B&M

Artikel-Nr.: 4220122

Set of 3 ribbed B M inserts Dia. 25 - 30 - 33 mm

Suction cup (top), dia. 26 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 26

Artikel-Nr.: 4220906

Suction cup (top), dia. 26 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 30 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 30

Artikel-Nr.: 4220907

Suction cup (top), dia. 30 mm for case opener with hand wheel Bergeon

Suction cup (top), dia. 34 mm for case opener with hand wheel Bergeon

Dimensions Ø mm: 34

Artikel-Nr.: 4220908

Suction cup (top), dia. 34 mm for case opener with hand wheel Bergeon

Replacements

Vice for housing, dia. 60 mm for case opener with hand wheel Bergeon

Artikel-Nr.: 235143

Spannbacken nicht im Lieferumgang enthalten.

Jaws for edges for case opener with hand wheel

Application: für Kanten

Artikel-Nr.: 4220011

Fits case openers 4220120 + 4220005 + 235142

Jaws for cuts for case opener with hand wheel

Artikel-Nr.: 4220012

Fits case openers 4220120 + 4220005 + 235142

Jaws for drilled holes for case opener with hand wheel

Application: 4220120 + 4220005 + 235142

Artikel-Nr.: 4220013

Fits case openers 4220120 + 4220005 + 235142

Jaws for ribbing for case opener with hand wheel

Application: für Riffelung

Artikel-Nr.: 4220014

Fits case openers 4220120 + 4220005 + 235142

Jaws for Aqua-Star for case opener with handwheel

Application: für Aqua-Star-Gehäuse

Artikel-Nr.: 4220015

Fits case openers 4220120 + 4220005 + 235142

Jaws for curved edges for case opener with hand wheel

Application: for curved edges

Artikel-Nr.: 4220016

Fits case openers 4220120 + 4220005 + 235142

Holding jaws, 9-11 mm for case opener with hand wheel Bergeon

Application: für Anstoß 9-11 mm

Artikel-Nr.: 4220021

Plastic for bracket distances from 9 - 11 mm

Holding jaws, 13-15 mm for case opener with hand wheel Bergeon

Application: für Anstoß 13-15 mm

Artikel-Nr.: 4220022

Plastic for bracket distances from 13 - 15 mm

Holding jaws, 17-19 mm for case opener with hand wheel Bergeon

Application: für Anstoß 17-19 mm

Artikel-Nr.: 4220023

Plastic for bracket distances from 17 - 19 mm

Holding jaws, 20-22 mm for case opener with hand wheel Bergeon

Application: für Anstoß 20-22 mm

Artikel-Nr.: 4220024

Plastic for bracket distances from 20 - 22 mm

Product information "Case opener with handwheel Bergeon"

For screwed case backs of all kinds. With flywheel, dia. 130 mm, for easy pressure and screw control. Upper vice "BIG" for housing dia. up to 60 mm. br
Includes: br
4 pairs of plastic holding jaws for different bracket distances 4 220 021 to 4 220 024 br
2 inserts for edges 4 220 011 br
2 inserts for cuts 4 220 012 br
2 inserts for holes 4 220 013 br
2 inserts for ribbing 4 220 014 br
2 inserts for AquaStar housing 4220015 br
2 inserts for curved edges 4220016 br
Mounted on plate.
