Bench vice Fortissimo Fix steel forged, 125mm jaw width
Product number:
331113
Packaging Unit:
1
Delivery time approx. 1 week
| Article name: | Bench vice |
|---|---|
| Brand: | Kanca |
| Clamping range: | 160 |
| Dimensions width mm: | 125 |
| Gross weight grams: | 9.300 |
0 of 0 reviews
Login
No reviews found. Be the first to share your insights.
Accessoires (optional)
- Forged steel
- enables 360 ° rotation of the vice
- Stepless locking by means of a locking screw
- Can also be used for models from other manufacturers
- ideal for vice reference 331113
- Dimensions Ø outside: 135mm
- Dimensions Ø inside: 129mm
- Overall width: 185mm
Product information "Bench vice Fortissimo Fix steel forged, 125mm jaw width"
According to the manufacturer, the Fortissimo Fix parallel vice is "100% unbreakable" - indestructible.
Forged from CF45 steel. CF45 steel is a special tempering steel for flame and induction hardening or surface hardening.
- The jaws and anvil are induction hardened.
- Adjustable guide guarantees precise clamping.
- Guide rails protected from dirt by wipers.
- With welded pipe clamping jaws.
- Guarantees precise and parallel clamping of workpieces.
- Tension: 4,000 to 4,500kg
Technical specifications:
- jaw width: 125mm
- Maximum span: 160mm
- Overall length: 388mm
- Anvil size: 50 x 70mm
- Base diameter: Ø 150mm
- Hole diameter: Ø 113mm
- Hole spacing: Ø 13.5mm
- Spindle wrench: Ø 15mm
- Jaw depth: 72.5mm
- Vice height: 139.6mm
- Weight: approx.9.3kg
- Measure for pipes / spans from 3/8 - 1 1/2 inches
- Lifetime manufacturer's guarantee (when used according to the instructions for use)
- TÜV-Süd checked
- GS mark for tested safety
- Matching turntable (reference 331115) optionally available
Forged from CF45 steel. CF45 steel is a special tempering steel for flame and induction hardening or surface hardening.
- The jaws and anvil are induction hardened.
- Adjustable guide guarantees precise clamping.
- Guide rails protected from dirt by wipers.
- With welded pipe clamping jaws.
- Guarantees precise and parallel clamping of workpieces.
- Tension: 4,000 to 4,500kg
Technical specifications:
- jaw width: 125mm
- Maximum span: 160mm
- Overall length: 388mm
- Anvil size: 50 x 70mm
- Base diameter: Ø 150mm
- Hole diameter: Ø 113mm
- Hole spacing: Ø 13.5mm
- Spindle wrench: Ø 15mm
- Jaw depth: 72.5mm
- Vice height: 139.6mm
- Weight: approx.9.3kg
- Measure for pipes / spans from 3/8 - 1 1/2 inches
- Lifetime manufacturer's guarantee (when used according to the instructions for use)
- TÜV-Süd checked
- GS mark for tested safety
- Matching turntable (reference 331115) optionally available
