Kieninger movements kit, JE, spring-controlled switchover movement, 8-gong
Product number:
341895
Packaging Unit:
1
Extra order! Delivery time approx. 2 weeks, return is not possible.
Downloads
| Article name: | Movements kit |
|---|---|
| Brand: | Kieninger |
| Calibre number sorting: | 0221 |
| Dimensions width mm: | 120,00 |
| Dimensions Ø mm: | 120,000 |
| Drive: | escapement |
| External dimension length: | 120,00 |
| Function: | pendulum |
| N° de calibre: | J0221 |
| Punch type: | 8-rod gong |
| Type: | mechanical |
Login
Product information "Kieninger movements kit, JE, spring-controlled switchover movement, 8-gong"
Movement kit, "JE", consisting of:
Calibre J0221 1/4 spring-controlled switchover movement (ZW3) in polished design with escapement (Swiss anchor rate, 11 jewels with screw balance), pinned reel with 3 melodies (Westminster, St. Michael, and Whittington) on 8-rod gong (120/140 mm, bottom strike, brass with bronze rods, base mounting, design height 93 mm), running time 7 days, PCB dimension 100 x 104 x 2.0 mm, 6 Aeterna bronze bouchons (spare wheels), spring housing with quick release axle, safety wind-up lock, seconds display, front wind
